Sony Full HD compact professional NXCAM camcorder HXR-NX100
Stunning quality from a large 1.0 type sensor
The HXR-NX100’s single 20 megapixel* 1.0 type Exmor R CMOS sensor is approximately the same size as a 16mm film frame and seven times larger than three 1/4.7 type sensors combined. The key benefit of this large size is low noise and less blur because more light reaches the sensor, offering clear and steady pictures even in a dark scene with minimum illumination 1.7 lux**. The large sensor size also enables beautiful background defocussing (bokeh) to enable you to focus on what you want to show and defocus the rest of the image.
Sony G Lens with maximum 48x zoom
A fixed 29mm wide-angle lens with 12x optical zoom makes it easy to capture even the most expansive landscape scenes while also offering superb clarity and sharpness – maximising the performance of the NX100’s large 1.0 type sensor. The G Lens is Sony’s own camera lens family, designed and manufactured to the high standards of optical performance. In addition, your ability to get into close with the most distant scenes is aided by Sony’s advanced Clear Image Zoom feature. Once you’ve zoomed in at maximum 12x optical magnification, By Pixel Super Resolution Technology can enlarge the image by additional 200% while still preserving image quality. In addition, zoom performance can be doubled at any point with a digital extender by up to 48x.
Manual operability in professional handy design
The HXR-NX100 is ergonomically designed to provide a lightweight and easy-to-use shooting experience. Three manual, independent lens rings enables smooth, natural adjustment of focussing, zooming and iris control. It can also be used in full-auto mode or completely manual for maximum creative control. Manual dial and buttons on the side of the body allow swift and easy adjustment of IRIS (aperture), GAIN and shutter speed. The white balance is simple to adjust by colour temperature in convenient 100K steps.
Built-in ND Filters
A built-in Neutral Density (ND) filter wheel includes positions for clear, 1/4 (2 stops), 1/16 (4 stops), and 1/64 (6 stops). This makes it easier to to get all the advantages of shallow depth of field even in exterior day shoots, with no need to worry about bringing along and fitting a separate filter.
Multi-format recording with DV, AVCHD and 50Mbps XAVC S
The HXR-NX100 is designed to provide the absolute best performance for Full-HD productions, recording in AVCHD and DV to support proven legacy workflows, as well as the newer, more advanced XAVC S at 50Mbps. XAVC S offers stunning picture quality, but also workflow flexibility and storage efficiency. In XAVC S, the HXR-NX100 uses the MP4 file format, sampling at 50 Mbps, and is already supported by all the major non-linear editors (NLEs). Compared to AVCHD, XAVC S 50Mbps captures more details and less noise thanks to the higher bitrate. Depending on your region, separate models are available offering recording frame rates of 50p, 50i, 25p Full HD and 50i SD (PAL model), or 60p, 60i, 30p, 24p Full HD and 60i SD (NTSC model).
Dual media slots for recording flexibility
To extend recording time and workflow flexibility, the NX100 is equipped with two memory card slots and is compatible with SDXC and SDHC cards as well as Memory Stick PRO Duo (Mark 2) and Memory Stick PRO-HG Duo. RELAY mode automatically switches recording from the first to the second memory card when the first is full, while SIMUL mode permits simultaneous recording to two memory cards (for example to create an immediate back-up version). The NX100’s two Start/Stop buttons on the handle grip, and camcorder body, can independently start and stop recording on different memory cards while recording in SIMUL mode.
High resolution LCD and EVF
The NX100 has a 0.24-type Electronic Viewfinder (EVF) and an easily adjustable, flip out 3.5-type LCD. Both offer 1550K dots high resolution for precise monitoring and low latency however you choose to shoot.
Multi-Interface (MI) Shoe
The HXR-NX100 takes advantage of Sony’s flexible Multi-Interface (MI) Shoe, which provides power, signal connections and coordinated on/off switching to compatible Sony accessories. For example, you can connect and control Sony wireless microphone systems such as the UWP-D11 or UWP-D12 or attach the HVL-LBPC light*.
Wide choice of connections
There’s no need to worry about adapters as the NX100 provides a wide variety of built-in connectivity options including HDMI, Multi/Micro USB, professional audio XLR terminals, REMOTE and Composite (BNC).
| Brand | Sony |
|---|---|
| Model | HXR-NX100 |
| Type | Camcorder |
| Effective Pixel | Approx. 14.2 M pixels (16:9)/Approx. 10.6 M pixels (4:3) |
| Lens Attachment | Fixed |
| Optical Zoom | 12x (optical), servo |
| Product Dimensions | 171.3 × 187.8 × 371.3 mm |
| Weight | 1.79 kg |
| Type of Lens | 1.0-type (13.2 mm x 8.8 mm) back-illuminated Exmor R CMOS sensor |
| Shutter Release Modes | PAL Model: [50i]: 1/6 -1/10,000 NTSC Model: [60i]: 1/8 - 1/10,000 (1/6 - 1/10,000 when shooting with 24p) |
| Lens Focal Length | f = 9.3 - 111.6 mm equivalent to f = 29.0 - 348.0 mm on 35 mm lens (16:9) equivalent to f = 35.5 - 426.0 mm on 35 mm lens (4:3) |
| Other Exposure Features | Slow & Quick Motion Function PAL Model: [50i]: 1080p: Frame rate selectable 1.2.3.6.12.25,50 fps NTSC model: [60i]: 1080p: Frame rate selectable 1.2.4.8.15.30,60 fps White Balance: Preset (Indoor: 3200K, Outdoor: 5600K±7 steps, Color temparature set range : 2300-15000K), Onepush A, B, Auto selectable |
| Other Lens Features | Iris: F2.8 - F4.5/auto/manual selectable Focus: AF/MF selectable, 10 mm to ∞ (Wide), 1000 mm to ∞ (Tele) Image Stabilizer: ON/OFF selectable, shift lens Filter Diameter: M62 mm Built-in Optical Filters: OFF: Clear, 1: 1/4ND, 2: 1/16ND, 3: 1/64ND Minimum Illumination: [60i] 1.7 lux (LOW LUX mode),[50i] 1.7 lux (LOW LUX mode) Gain: -3, 0, 3, 6, 9, 12,15, 18, 21, 24, 27, 30, 33 dB, AGC Gamma Curve: Selectable |
| Video Format | XAVC S HD：MPEG4-AVC/H264 4:2:0 Long profile AVCHD : MPEG-4 AVC/H.264 AVCHD 2.0 format compatible DV |
| Audio Format | XAVC S HD : Linear PCM 2ch, 16bit, 48kHz AVCHD : Linear PCM 2ch, 16-bit, 48 kHz / Dolby Digital 2ch, 16-bit, 48 kHz DV : Linear PCM 2ch, 16-bit, 48 kHz |
| Frame Rates in Video Modes | PAL XAVC S (1920 x 1080)@50p, 25p, 50 Mbps AVCHD (1920 x 1080)@50p, PS mode (28 Mbps) AVCHD (1920 x 1080) @50i/25p, FX mode (24 Mbps) FH mode(17 Mbps) AVCHD (1440 x 1080)@50i, HQ mode (9 Mbps) LP mode (5 Mbps) AVCHD (1280 x 720)@50p, FX mode (24 Mbps) FH mode (17 Mbps) HQ mode (9 Mbps) DV (720 x 576) @50i, 25 Mbps NTSC XAVC S (1920 x 1080)@59.94p, 29.97p, 23.98p, 50 Mbps AVCHD (1920 x 1080)@59.94p, PS mode (28 Mbps) AVCHD (1920 x 1080) @59.94i/29.97p/23.98p, FX mode (24 Mbps) FH mode(17 Mbps) AVCHD (1440 x 1080)@59.94i, HQ mode (9 Mbps) LP mode (5 Mbps) AVCHD (1280 x 720)@59.94p, FX mode (24 Mbps) FH mode (17 Mbps) HQ mode (9 Mbps) DV (720 x 480) @59.94i, 25 Mbps |
| Recording Features | Recording/Playback Time XAVC S HD@LPCM 2ch 50 Mbps Approx. 155 min with 64 GB memory card AVCHD@LPCM 2ch PS Mode Approx. 290 min with 64 GB memory card Approx. 145 min with 32 GB memory card AVCHD@LPCM 2ch FX Mode Approx. 340 min with 64 GB memory card Approx. 170 min with 32 GB memory card AVCHD@LPCM 2ch FH Mode Approx. 450 min with 64 GB memory card Approx. 225 min with 32 GB memory card DV Approx. 280 min with 64 GB memory card Approx. 140 min with 32 GB memory card |
| USB | Multi/Micro USB jack (x1) |
| HDMI | Type A (x1) |
| Other Connectivity Features | Audio Input: XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable Video Output: BNC (×1), Composite, 1.0Vp-p, 75 Ω Audio Output: RCA pin Headphone Output: Stereo mini jack (x1) Speaker Output: Monaural DC Input: DC jack Remote: Stereo mini mini jack (x1) |
| Card Type | Memory Stick Pro Duo(TM) and SD/SDHC/SDXC compatible( x1) SD/SDHC/SDXC (x1) |
| Power Supply | Approx. 5.2 W (while recording with viewfinder and AVCHD 1080/60i FX) Approx. 5.4 W (while recording with LCD and AVCHD 1080/60i FX) |
| Power Requirement | DC In: 8.4V Battery: 7.2 V |
| Battery Life | Approx. 345 min. with NP-F770 battery (while recording with LCD, AVCHD 1080/60i FX) Approx. 445 min. with NP-F770 battery (while playing with LCD, AVCHD 1080/60i FX) |
| Other Power Features | Operating Temperature: 0°C to 40°C Storage Temperature: -20°C to +60°C |
| View Finder Coverage | 0.6cm(0.24 type) Approx. 1.56 M dots. |
| Other Additional Features | LCD: 8.8 cm (3.5 type)/Approx. 1.56 M dots. Built-in Microphone: Omni-directional stereo electret condenser microphone. |
| In the box | New Charger (1) Lens hood (1) Lens cap (1) Large eyecup (1) Shoe cap (1) USB cable (1) Rechargeable battery pack (NP-F770) (1) AC Adaptor (AC-L100C) (1) Power cord (mains lead) (1) Wireless Remote Commander (RMT-845) (1) Lithium battery (CR2025 for the Wireless Remote Commander, pre-installed to the Wireless Remote Commander) (1) Operating Guide (2) CD-ROM (1) Warranty (1) |
| Warranty Period | 1 Year Manufacturer Warranty |
